Low pressure screw compressors
Optimized Two-Stage Compression for Maximum Efficiency
The Baldor PM-II & LPM-II Series are high-performance two-stage permanent magnet screw air compressors, engineered to provide exceptional energy savings, ultra-reliable operation, and long-lasting performance. Featuring IE4 Permanent Magnet Motors, Optimized Two-Stage Compression Technology, and an Intelligent IoT Control System, these compressors are the perfect solution for industrial applications requiring high-efficiency compressed air.
Technical Specifications
|
Model
|
BD-390LPM/3
|
BD-390LPM/5
|
BD-600LPM/3
|
BD-600LPM/5
|
BD-750LPM/3
|
BD-750LPM/5
|
BD-1100LPM/3
|
BD-1100PM/5
|
BD-1560LPM/3
|
BD-1560LPM/5
|
||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Power(kw)
|
37
|
45
|
55
|
75
|
75
|
90
|
110
|
132
|
132
|
160
|
||
|
Pressure(bar)
|
3
|
5
|
3
|
5
|
3
|
5
|
3
|
5
|
3
|
5
|
||
|
FAD(m³/min)
|
11.5
|
11.5
|
18.5
|
18.5
|
25.5
|
22.5
|
35.7
|
31.2
|
44.2
|
40.5
|
||
|
Ambient temp
|
-5~+45℃
|
|||||||||||
|
Cooling Way
|
Air Cooling or Water Cooling
|
|||||||||||
|
Discharte temp
|
Air cooling(ambient temperature±10℃) water cooling(＜40℃)
|
|||||||||||
|
Electricity
|
220v/380v/415v/460v/50hz/60hz
|
|||||||||||
|
Starting Method
|
Inverter Start
|
|||||||||||
|
Drive way
|
Direct Drive
|
|||||||||||
|
Lubricant(Litre)
|
72
|
72
|
120
|
120
|
120
|
120
|
150
|
150
|
208
|
208
|
||
|
Noise(dBA)
|
66±2
|
68±2
|
68±2
|
68±2
|
75±2
|
75±2
|
77±2
|
77±2
|
78±2
|
78±2
|
||
|
Length(mm)
|
1250
|
1250
|
1450
|
1450
|
1600
|
1600
|
1800
|
1900
|
2200
|
2200
|
||
|
Width(mm)
|
800
|
800
|
900
|
900
|
1150
|
1150
|
1250
|
1250
|
1550
|
1550
|
||
|
Height(mm)
|
1000
|
1000
|
1250
|
1250
|
1370
|
1370
|
1550
|
1650
|
1800
|
1800
|
||
|
Weight(kg)
|
400
|
450
|
580
|
610
|
900
|
930
|
1080
|
1280
|
2880
|
3080
|
||
|
Outlet Pipe Dia(inch)
|
G1¼”
|
G1¼”
|
G1½”
|
G1½”
|
G2″
|
G2″
|
G2″
|
G2″
|
DN80
|
DN80
|
||
