Permanent Magnet Screw Air Compressors
Revolutionizing Industrial Air Compression with LS Series Technology
The Baldor LS Series is an ultra-quiet, energy-efficient, and intelligent air compressor designed for high-end industrial applications. Utilizing IE4 Permanent Magnet Motors, Variable Speed Drive (VSD) Technology, and an Advanced Intelligent Control System, the LS Series provides exceptional reliability, ultra-low noise levels, and optimal energy efficiency.
Features:
- Super Quiet Design – Operates at as low as 58 dB(A) for a noise-free working environment.
- IE4 Permanent Magnet Motor – Reduces energy consumption by up to 50% compared to traditional models.
- Variable Speed Drive (VSD) – Dynamically adjusts output based on real-time demand, maximizing efficiency.
- Integrated Intelligent Control System – Features remote monitoring, predictive maintenance, and smart automation.
- Optimized Cooling System – Ensures stable operation even in high-temperature industrial environments.
Technical Specifications
|
Model
|
M/min
|
Power
|
Size(mm)
|
Inch
|
KG
|
DB(A)
|
Liter
|
|---|---|---|---|---|---|---|---|
|
BD-LS11
|
0.73-1.82
|
11
|
1083 x 720 x 1230
|
ZG1″
|
340
|
65±2
|
10
|
|
BD-LS15
|
0.99-2.48
|
15
|
1083 x 720 x 1230
|
ZG1″
|
340
|
65±2
|
10
|
|
BD-LS22
|
1.52-3.8
|
22
|
1295 x 860 x 1400
|
ZG1-1/4″
|
400
|
65±2
|
16
|
|
BD-LS37
|
2.48-6.2
|
37
|
1576 x 980 x 1620
|
ZG1-1/2″
|
615
|
65±2
|
25
|
|
BD-LS45
|
2.96-7.4
|
45
|
1576 x 980 x 1620
|
ZG1-1/2″
|
640
|
65±2
|
25
|
|
BD-LS55
|
4.24-10.6
|
55
|
1865 x 1150 x 1800
|
ZG2″
|
925
|
68±2
|
45
|
|
BD-LS75
|
4.72-11.8
|
75
|
1865 x 1250 x 1900
|
ZG2″
|
1250
|
68±2
|
60
|
